RADIANT HEATING PANELS
ECOSUN S09 — S12 — S18 — S24 — S30 — S36
INSTALLATION INSTRUCTIONS
1. GENERAL INFORMATIONS
1.1. Panels are class I, IP X4.
1.2. Panels have to be installed under correspond local electric standards.
1.3. Panels installation have to be provided by qualified person only.
2. USING
These panels are determined for heating of bigger spaces. There are recommended mainly for industry halls, workshops, etc.
storage areas, shops, sports and common halls. They can be used for zone heating of requested areas too.
In aggressive environments, in areas with heightened dampness (coastal regions, car washes, ...) corrosion can occur, shorten-
ing the lifetime of panels. In these areas we recommend the installation of SBs type corrosion- proof panels with the same
wattage as our S panels.
3. ASSEMBLY
Panels are suspended on four fixation points by chain or can be fix to auxiliary frame. Auxiliary frame is fixed to ceiling with
screws.The fixtures are supplied in a dismantled state and you have to attach them before installation. The fixtures can be
replaced by a swivel fixture – a swivel hinge (not part of the packaging).
Picture No.1 — Panels fixation
Position of panel is necessary to fix by set screws against accidental pull out.
The radiant panel can be installed at an angle or vertically. However, it must not be installed at an angle or vertically in
such a way that the terminal strip is located on the highest point of the panel. When the panel is angled an increase in
heat convection occurs, and this heat will irreversibly damage the electrical components of the terminal strip.
