4. INSTALLATION

4.1 Important installation information
• Read and follow all instructions in the SAFETY INFORMATION section.
• Refer to the separate manuals supplied with the other components for more
relevant information.

4.2 Before installation

Step
1
2
4.3 Before installation
Step
1
2
Action
Make sure that you have the following installed in your kitchen cabinet
(see image 3):
• Discharge pipe with siphon (Ø 40 mm)
• Earthed AC wall socket (with 16A fuse)
• Cold water supply (with water of drinking water quality and with a
3/8" outer thread)
• Warm water supply (with a 3/8" outer thread). If not available you
need to follow the instructions for the combi configuration.
Rinse all supplied hoses with water thoroughly
Action
Determine which configuration you are going to install.
The appliance is available for 2 different configurations:
• Solo situation (see image 4)
• Combi situation (see image 5)
The solo configuration supplies only boiling water. Warm water comes
from the central boiler.
The combi configuration supplies both boiling and warm water.
Make sure you have all components.
If you install the solo configuration:
– Make sure you have the following components: A, B, C and E
(optional). Make sure everything is complete and that no parts are
missing (see image 1).
If you install the combi configuration:
– Make sure you have the following components: A, B, C, D and E
(optional). Make sure everything is complete and that no parts are
missing (see image 1).
