3.5 Main components mixing valve (for combi situation only;
see image 2)
Part Description
27 Boiling water inlet or outlet (indicated by "H")
28 Boiling water inlet or outlet (indicated by "H")
29 Warm water outlet (indicated by "MIX")
30 Cold water inlet (indicated by "C")
31 Cold water outlet
32 Seal
33 Cold water inlet
34 Temperature regulator
35 Extension hose
3.6 Main components filter (optional; see image 2)
Part Description
36 Bracket
37 Water inlet
38 Filter head
39 Cartridge
40 Filter hose
41 Water outlet
42 Flow meter
