Bell UPF 252 Gebrauchs- Und Wartungsanleitung Seite 39

LISTA RICAMBI - LIST OF SPARE PARTS (TAB. 2)
KEY DESCRIZIONE
11 O-RING
12 VITE AUTOFILETTANTE
50 RACCORDO COPERCHIO-TESTATA
51 FORCELLA BLOCC.RACCORDO
52 O-RING
53 GUARNIZIONE TENUTA FRONT.
54 BOCCOLA FERMO O-RING
55 O-RING
56 V.T.S.E.I.M5X0,8X25
57 TAPPO TESTATA
58 FORCELLA BLOCC.TESTATA
59 TESTATA
60 PERNO PISTONE INVERT.
61 GUARNIZIONE CANNA
62 GUARNIZIONE
63 PISTONE INVERTITORE
64 GUARNIZIONE CANNA-TESTATA
65 CANNA
66 RONDELLA DI TENUTA
67 VITE
68 TENUTA
69 PISTONE
70 POMPANTE UPF702 - UPF705
70 POMPANTE UPF502 - UPF505
70 POMPANTE UPF252 - UPF255
71 RONDELLA FERMO MOLLA UPF702 - UPF705
71 RONDELLA FERMO MOLLA UPF502 - UPF505
71 RONDELLA FERMO MOLLA UPF252 - UPF255
72 AMMORTIZZATORE UPF702 - UPF705
72 AMMORTIZZATORE UPF502 - UPF505
72 AMMORTIZZATORE UPF252 - UPF255
73 MOLLA POMPANTE
74 RONDELLA RAME
75 SEDE PERNO ALIMENTAZIONE
76 RONDELLA RAME
77 GUIDA SFERA
78 MOLLA PERNO ALIMENTAZIONE
79 SFERA D.1/4"
80 ANTIEST.
81 O-RING
82 PERNO ALIMENTAZIONE
83 RONDELLA RAME
84 CORPO POMPA UPF702 - UPF705
84 CORPO POMPA UPF502 - UPF505
84 CORPO POMPA UPF252 - UPF255
85 GUARNIZIONE UPF702 - UPF705
85 GUARNIZIONE UPF502 - UPF505
85 GUARNIZIONE UPF252 - UPF255
86 TESTATA GUIDA POMPANTE UPF702 - UPF705
86 TESTATA GUIDA POMPANTE UPF502 - UPF505
86 TESTATA GUIDA POMPANTE UPF252 - UPF255
87 RACCORDO FILTRO ASP.
88 FILTRO OLIO
89 ANELLO SEEGER
90 MOLLA RACC.ASPIRAZ.OLIO
91 RONDELLA SUPPORTO MOLLA
92 O-RING
93 SUPPORTO FASCETTA
94 STRINGITUBO STANDARD
95 O-RING
96 FLANGIA
97 ANELLO SEEGER
98 RACCORDO VALV.DI MASSIMA
99 GUARNIZIONE
100 SFERA D.1/8"
101 GUIDA SFERA VALV.MAX
102 MOLLA VALV.DI MASSIMA
103 GRANO FORATO VALV DI MAX
• SEAL KIT UPF 252 - 800050080 • SEAL KIT UPF 502 - 800050090 • SEAL KIT UPF 702 - 800050070
• SEAL KIT UPF 255 - 800050100 • SEAL KIT UPF 505 - 800050150 • SEAL KIT UPF 705 - 800050110
DESCRIPTION
O-RING
THREAD-FORMING SCREW
COVER-HEAD ADAPTER
LOCKING ADAPTER STAPLE
O-RING
SEAL
BUSHING
O-RING
SCREW M5X0,8X25
HEAD PLUG
LOCKING HEAD STAPLE
HEAD
PLUNGER
SEAL
U CUP
PISTON
SEAL
CYLINDER
WASHER SEAL
SCREW
SEAL
PISTON
PISTON UPF702 - UPF705
PISTON UPF502 - UPF505
PISTON UPF252 - UPF255
SPRING WASHER UPF702 - UPF705
SPRING WASHER UPF502 - UPF505
SPRING WASHER UPF252 - UPF255
BUMPER UPF702 - UPF705
BUMPER UPF502 - UPF505
BUMPER UPF252 - UPF255
SPRING
COPPER WASHER
FEED PIN SEAT
COPPER WASHER
BALL GUIDE
SPRING
BALL 1/4"
BK-RING
O-RING
PLUNGER
COPPER WASHER
BODY UPF702 - UPF705
BODY UPF502 - UPF505
BODY UPF252 - UPF255
SEAL UPF702 - UPF705
SEAL UPF502 - UPF505
SEAL UPF252 - UPF255
PISTON GUIDE HEAD UPF702 - UPF705
PISTON GUIDE HEAD UPF502 - UPF505
PISTON GUIDE HEAD UPF252 - UPF255
SUCTION FILTER ADAPTER
OIL FILTER
RETAINING RING
SPRING
SPRING SEAT WASHER
O-RING
STRAP SUPPORT
STANDARD PIPE CLAMP
O-RING
COVER
RETAINING RING
PEAK VALVE ADAPTER
SEAL
BALL 1/8"
PEAK VALVE BALL GUIDE
PEAK VALVE SPRING
PEAK VALVE BORED SPRIG
BEST./PART Nr.
425830021
426446355
309040010
141070010
425830084
139200010
116010010
425830006
426116057
182050030
141070020
184000060
102170010
139200050
425121044
160900020
139220090
309000020
141480030
426310137
425620210
160900010
160900040
160900060
160900041
141500120
141500150
141500140
139220030
139220030
139220031
151050310
451430007
172150040
451436006
150050020
151100090
428620042
425784034
425837022
102040030
451435006
131050050
131050070
131050060
425000021
425000070
425000031
184000050
184000050
184000050
128510021
139000010
427160090
151100100
141500110
425830108
177000030
427102100
425830136
147130020
427150350
128630030
425000110
E28620022
150060050
151050290
141400060
