Care and cleaning
Change oven light bulb
The light bulb is particularly heat-resistant
To replace it, proceed as follows:
• Disconnect in any case the device from the power sup-
ply (pull the plug or remove the fuse), because it can be
under power
• Turn out the glass and replace it with a new of the same
type (see right figure).
• Screw back the cover glass.

Inside the oven

5
4
2
1
3
2
6
2
4
3
1
2
1
Remove the hook in racks
Remove accessories such as rust and baking sheet.
Slightly push down the hook-in racks at the clamping point
(figure 2) and slide out.
Swivel hook in racks inside and unhook at the top (1 in figure)

Insert hook in racks

Insert the siderails up in the holes and swing it down.
At the cramping point, push down slightly siderails and push
towards side wall.
The hook in racks must engage tight.
1 Hook-in racks with rack levels
2 Lighting
3 Fan with ring heater
4 Grill heating element
5 Top element
6 Bottom heat radiator (under the oven floor)
1 to 4 :
Shelf levels for shelf unit, baking tray or roasting pan. Ple-
ase note that the numbering of the rack levels from bottom
to top.
