Connections (Continued)

Speaker System Connection

Connect the speakers using the supplied speaker cords.
To obtain the best possible surround sound, adjust the speaker parameters (volume, distance, etc.).
Notes
Be sure to match the speaker cable to the appropriate terminal on the components: + to + and – to –. If the cables are
reversed, the sound will be distorted and will lack base.
If you use front speakers with low maximum input rating, adjust the volume carefully to avoid excessive output on the speakers.
Do not disassemble the front covers of supplied speakers.
Speaker stand is optional.
About Ferrite Core
Be sure to attach the ferrite core to the speaker cables
(for connecting to this unit).
This ferrite core can reduce noises.
How to attach the ferrite core
Press the stopper [a] of the ferrite core to open.
1
Wind the Subwoofer cable once on the ferrite core.
2
Wind the Center cable once on the ferrite core.
Pass the others straight on the other ferrite core.
3
Close the ferrite core unit it clicks.
4
Notes
Take care not to pinch the speaker cables between the ferrite
cores.
Attach the ferrite core near the unit (Refer to the fig.3 and
comment.).
Downloaded From TheatreSystem-Manual.com Manuals
14
1
a
2
3
a
The length here is
short as much as
possible.
