Installation

Installing and connecting target modules

Connecting target computers to target modules

IMPORTANT:
The
technology which comply with laser class 1.
They meet the requirements in accordance to
and
U.S. CFR 1040.10
Mind the following instructions when dealing with laser beams:
 Avoid direct eye exposure to beam on page 3
 Always connect optical connections or cover them with protection caps on page 3
 Only use G&D certified transmission modules on page 3
 Connect the target computer to the different target modules.
The steps required to connect these devices are described in the manual supplied
with the modules:
Manual
Standard variants
Devices with integrated USB
DP-HR variants
DP-HR-U variants

Connecting target modules to the central module

IMPORTANT:
Mind the following instructions when installing central modules
with fiber ports:
 Avoid direct eye exposure to beam on page 3
 Always connect optical connections or cover them with protection caps on page 3
 Only use G&D certified transmission modules on page 3
 Connect the Trans. interfaces of each individual target module to one of the
Dynamic Ports of the central module.
2 4 6
Tx Rx Tx Rx Tx Rx Tx
Rx 1 Tx Rx 3 Tx Rx 5 Tx Rx
IMPORTANT: The DVI-CPU-UC target module provides two Trans. interfaces. Only
connect one Trans. interface of the target module to the matrix switch.
9 · G&D ControlCenter-Compact
