Installation
Installation
NOTE:
The following drawings refer to the
ent variants vary in the number of dynamic ports and the transmission medium
(CAT/Fiber) to connect user modules and target modules.
The following pages describe the installation of the devices of the KVM system.
NOTE:
When choosing a place for the device, please ensure to comply with the
ambient temperature limit (see Technical data on page 28) close to the device. The
ambient temperature limit must not be influenced by other devices.
Power supply
18
20
22
24
17
19
21
23
Main Power:
Plug one of the supplied power cable in this interface. Connect the
power cable with a power outlet and turn the power button on.
If required, plug one of the supplied power cable in this interface to
Red. Power:
establish a redundant power supply. Connect the power cable with a power outlet of
another power circuit and turn the power button on.
7 · G&D ControlCenter-Compact
26
28
30
32
25
27
29
31
ControlCenter-Compact-16F16C
Power
Red.
Main
Status
Ident.
Fail
Portfunction
. The differ-
Red. Power
Red. Power
Main Power
Main Power
