Instrument Description
Œ
Metal ball
Display - LCD
Ž
Button - Power - ON/OFF
Button - MAX/MIN
Button - Hintergrundbeleuchtung
‘
Button - MEAS
’
Battery cover
Button function
- Power Button - Turn the meter power ON or OFF
- MEAS Button - Press the MEAS button, the instrument will start measuring.
Release this button the „HOLD" icon will appear on the LCD indicating that the
current reading is being held.
- MAX/MIN Button - When taking measurements, press MAX/MIN Button, the
„MAX" icon will appear on LCD display and the meter will begin keeping track of
MAX value. Press the button again, „MIN" icon will appear on LCD display and
the meter will begin keeping track of MIN value. Press MAX/MIN button for two
seconds to exit this mode.
- Backlight Button - Turn the backlight on or off.
Instrument Check
- Hold the instrument as near to the back as possible. Press the „MEAS" button
and hold the instrument with the ball in the air. The displayed value must be
between -5 and +5.
Operation
Hold the instrument as near to the back as possible. Press the „MEAS" button and
use the ball to scan the surface under investigation. The ball must be in fi rm contact
with the material. To obtain the best results, the instrument should be held at an
angle of 90° to the surface to be measured.
1340 - 5643 - 0709
Œ
MME 200
Ž
‘
’
9
