Before Use; Installation; Product Setup; Assembling The Product - FLORABEST FSG 85 D1 Originalbetriebsanleitung

Switch off the product and unplug from the
mains
- to remove a jammed insertion tool,
- if the mains cable is damaged or entangled,
- if you notice unusual noise.

Before use

Note: Remove all packaging material from the
product.
The operator should stand in front and stay
close to the power tool to prevent overreach.

Installation

Note: Always use the included screws
(M10 x 60) to secure the product.
Ensure you will have adequate space to
work in and will not put others at risk.
Always secure the product to the worktop
with screws of an adequate length and
thickness to always maintain control over
the product.
Product setup (see Fig. B)
- Required thickness of the edge of the table:
15–30 mm
- Drill diameter: 10.5 mm
- Size of screw: M10
Use the stop notches
product on the worktop
base must extend beyond the edge of
8
the table.
Mark the bores with a pencil and remove
the product.
Now drill two holes in the worktop
Fasten the grinding base to the worktop us-
ing the included screws
and nuts .
24b
10 GB/IE/NI/CY
to position the
9
. The grinding
22
.
22
, washers
23 24a

Assembling the product

(see Fig. C)
Screw the handle to the grinding
4
head .
2
Loosen the locking screw
tensioner .
12
Attach the chain tensioner
ing base and tighten with the locking
8
screw .
10
If applicable, attach the mains cable
inside the cable holder
Attaching the adjusting
screw (see Fig. C)
Place the included washer
adjusting screw .
6
Screw the adjusting screw
fixed inside the grinding head.
26

Initial use

CAUTION! RISK OF INJURY!
Only use grinding discs and accessories
recommended by the manufacturer. Using
tools or accessories other than those recom-
mended in the instructions for use could
result in injury.
Never operate the product without visual
cover.
Do not use saw blades.
Always unplug from the mains before work-
ing on the product.
Inspect the grinding disc prior to use: Check
the clearance between the visual cover and
grinding disc.
Do not use damaged or deformed grinding
discs.
Do not switch on the product until it has
been firmly secured to the worktop.
CAUTION! RISK OF INJURY!
Wear eye and hearing protection.
on the chain
10
to the grind-
12
17
.
16
over the
25
to the locknut
6
