18 | English

Intended Use

The machine is intended for hammer drilling in
concrete, brick and stone. It is also suitable for
drilling without impact in wood, metal, ceramic
and plastic. Machines with electronic control
and right/left rotation are also suitable for
screwdriving.
Use the battery charger only when you fully un-
derstand and can perform all functions without
limitation, or have received appropriate instruc-
tions.

Product Features

The numbering of the product features refers to
the illustration of the machine on the graphics
page.
1 SDS-Quick tool holder
2 Dust protection cap
3 Locking sleeve
4 Selector switch for drilling/hammer drilling
5 Battery charge-control indicator
6 Indicator for right rotation
7 Indicator for left rotation
8 Rotational direction switch
9 On/Off switch
10 Universal bit holder*
11 Screwdriver bit*
12 Screwdriver bit with ball catch*
13 Drill bit with hexagon shank*
14 Drill bit with SDS-Quick tool holder*
15 Handle (insulated gripping surface)
16 Socket for charge plug
17 Charge connector
*Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
2 609 003 546 | (13.4.10)

Technical Data

Cordless Rotary
Hammer
Article number
Rated voltage
Rated speed
Impact rate
Impact energy per
stroke
Tool holder
Max. drilling dia.
– Concrete (with twist
drill)
– Steel
– Wood
Weight according to
EPTA-Procedure
01/2003
Battery
Capacity
Number of battery cells
Battery Charger
Article number
Charging time
Please observe the article number on the type plate of
your machine. The trade names of the individual ma-
chines may vary.

Noise/Vibration Information

Measured sound values determined according
to EN 60745.
Typically the A-weighted noise levels of the
product are: Sound pressure level 84 dB(A);
Sound power level 95 dB(A). Uncertainty
K =3 dB.
Wear hearing protection!
Uneo
3 603 J52 0..
V= 14.4
-1
min 0–900
-1
min 0–4800
J 0.9
SDS-Quick
mm 10
mm 8
mm 10
kg 1.1
Li-Ion
Ah 1.3
4
2 607 225 463
(EU)
2 607 225 465
(UK)
2 607 225 641
(AU)
h 3
Bosch Power Tools
