Applications
The unique Dual-Voice design of the KSM313 produces discrete front and rear sonic signatures.
Position the sides, the null points of a bidirectional microphone, towards any unwanted sound sourc-
es. Some typical applications are listed below.
Address the front for a warmer,
darker tone
• Electric guitar amplifiers
• Brass and woodwind
instruments
• Upright bass
• Kick Drum

Mounting the Microphone

Thread the supplied stand adapter onto a floor or boom stand and insert the microphone.
Note: To reduce low-frequency vibrations transmitted through the stand, use an isolating shock
mount. Visit www.shure.com for more information.
Front
Stand Mount
(furnished)
Address the rear* for a brighter
tone with increased presence
• Vocals
• Acoustic string instruments
• Drum overheads and
percussion
*When addressing the back side of a bidi-
rectional mic, please remember to invert the
signal polarity. Shure's A15PRS accessory is
an in-line, balanced, polarity-reversing switch
capable of this operation and is available on-
line at: store.shure.com
Suspension Mount
(optional accessory)
5
Back
