INStRUCtIoN oF USE

GB
ERECTING (fig 1).
Release transportation-lock.
UNFOLDING (fig. 2a, 2b)
Tip forward to open the stroller, and press down both cross bars (top & bottom) at the back of
the stroller until they are securely engaged.
FRONT WHEEL ASSEMBLY (fig. 3a, 3b)
Push both front wheels into position. Make sure the pushpin locks in place and cannot be pull
off (3a). When changing the wheel, lie the stroller down in fully assembled state. Press both
levers on the wheel frame and pull complete double wheel out to the front (3b).
FRONT WHEEL ADJUSTMENT (fig 4)
Slide the front wheel lever up to lock the swivel movement. to release the swivel movement,
slide the lever down.
REAR WHEEL ASSEMBLY (fig. 5)
Push the rear wheels onto the rear leg. Make sure the pushpin locks in place and cannot be pull
off. When changing the wheel, reverse the sequence.
TWIN BRAKE FOR REAR WHEELS (fig. 6)
Press both brakes down to stop the rear wheels and push the stroller to check.
Attention: Always apply both brakes when parking the stroller.
ADJUSTING THE BACK REST (fig. 7)
Adjust the left & right levers to alter the position of the back rest at 5 different seat positions.
ADJUSTING THE LEG REST (fig. 8)
Press both (left & right) buttons to bring the leg rest to the desired position.
CANOPY ASSEMBLY (fig. 9)
Attach the clamping device of the canopy to both sides of the stroller frame.
OPEN THE SAFETY FRONT BAR (fig. 10a, 10b)
Release the safety lever with your finger from below. Pull the front bar forward to open (10a).
To close the front bar, push the plastic clip to the armrest housing (10b). Make sure the front
bar is securely locked and cannot be pull off before using the stroller.
FOLDING AWAY (fig. 11):
Return the backrest to the sitting position.
a. Lift up the primary safety lock with your foot;
b. press down the top safety lock by your foot and push the handle forward to close the
stroller;
Secure the stroller with the transportation-lock.
SECURE THE CHILD IN THE SEAT BY 5-POINT SAFETY BELT (fig 12):
Place the child in the seat and push the clips on the waist belt into the buckle on the crotch belt
(the one that comes between the child's legs). Adjust the length of the belt to your child's needs.
Always ensure the straps are not twisted or caught on the stroller frame. Check the adjustment
every time you place the child in the seat and when the backrest is reclined. To release the
harness, squeeze & open the buckle.
Harness adjustment: Insert both fasteners (B) into the buckle (A), ensure that both buttons click
into position. Ensure both shoulder straps (C) are attached to the fasteners (B). Each strap has
its own length adjuster (D). To undo the harness, press the button and pull apart. "D" Rings are
provided for fitment of a full safety harness. The attachment points (D-rings) are located on side
straps.
WARNING: (A child's safety is your responsibility.) The child should be harnessed in at all times
and should never be left unattended. the child should be clear of moving parts while making
adjustments. This stroller requires regular maintenance by the user.
Attention: Avoid serious injury from failing and sliding out, always use seat belt & always use
as instructed. Never use the harness without the shoulder straps.
13. ADJUSTING THE SHOULDER HARNESS (fig. 13)
there are 2 shoulder harness height available in the stroller, use the slot closest to child's
shoulder height.
oPtIoN FEAtURES – SHoP N DRIVE tRAVEL SYStEM:
This stroller is able to adapt our Hauck Zero Plus® Infant Carseat as a Travel System. To adapt the
carseat, please follow the following steps:
Detach the armrest cover on the stroller and you can find an adaptor clip on the each side of the
stroller's folding plastic, pull both of them up. (figure A).
Release the stroller seat to the lowest recline position. Place the zero Plus® Infant Carseat on
top of the stroller's front bar. (figure B).
Push the Zero Plus® Infant Carseat down until you hear the clip sound on both left & right sides
(figure C1, C2). Lift up carefully the carseat to check if the carseat is securely locked in place.
To release the carseat, push up the left & right levers, which are located underneath the carseat,
and the adaptors can be released. (figure D1). Then lift up the carseat carefully (figure D2), and
close the adaptors back to the original housing (figure D3).
