List Of Parts - Sartorius 16692 Betriebsanleitung

Teilebezeichnung
Bezeichnung
Reduzierventile
Tragegriff
Netzschalter
Lüfterhaube
Gehäuse
Typenschild
Ausgang
Membrankopf
Inbusschrauben (4 Stück) Nr. 9
Eingang
Inbusschrauben (7 Stück) Nr. 11
Deckel
12
11
10
9
8
7
Abb.1 | Fig.1
in dem Foto
Nr. 1
Nr. 2
Nr. 3
Nr. 4
Nr. 5
Nr. 6
Nr. 7
Nr. 8
Nr. 10
Nr. 12
1 2
6 5

List of Parts

Designation
Reducing valves
Carrying handle
Power switch
End cover plate (for fan) No. 4
Housing
Manufacturer's label
Outlet connector
Diaphragm head
Allen screws (4)
Inlet connector
Allen screws (7)
Cover plate
Shown in photo as
No. 1
No. 2
No. 3
No. 5
No. 6
No. 7
No. 8
No. 9
No. 10
No. 11
No. 12
