Intended Use
The machine is intended for trimming edges in
wood, plastic and light building materials. It is
also suitable for routing of grooves, profiles and
slots as well as for contour routing.
Mounting
I Before any work on the machine itself, pull
the mains plug.
Disassembling the Motor Unit
(see figure )
A
For disassembly of the motor unit 1, open the
clamping lever 10 and turn the routing base 2 so
that the "L" mark is in line with the "
on the motor unit. Then pull the motor unit 1 up-
ward to the stop, turn the motor unit 1 in anti-
clockwise direction to the stop and pull the mo-
tor unit 1 out of the routing base 2.
Router Bit Selection
Depending on processing and application,
router bits are available in the most different de-
signs and qualities:
Router bits made of high speed steel (HSS)
are suitable for the machining of soft materials,
e. g., softwood and plastic.
Carbide tipped router bits (HM) are especially
suitable for hard and abrasive materials, e. g.,
hard wood.
Original router bits from the extensive Bosch ac-
cessories program are available at your special-
ist shop.
Inserting Router Bits
(see figures + )
B C
I Before any work on the machine itself, pull
the mains plug.
I It is recommended to wear protective gloves
when inserting or replacing router bits.
Disassemble the motor unit as described in the
respective section.
Press the spindle lock button 9 and keep it
pressed. Possibly turn the spindle by hand until
the lock engages.
I Press the spindle lock button only when at a
standstill.
Loosen the collet chuck 5 with an open-end
spanner 12 (size 18 mm) several turns, but do
not unscrew the tightening nut.
16 | English
Insert the shank of the router bit at least 20 mm
(shank length) into the collet.
Tighten the collet chuck 5 with the open-end
spanner 12 (size 18 mm) and release the spin-
dle lock button 9.
Do not tighten the tightening nut of the
collet chuck without a router bit in-
serted.
Replacing the Collet (see figure
Depending on the routing tool to be used, differ-
ent collets can be inserted, see "Tool Specifica-
tions".
The collet 13 must have somewhat play when
seated in the tightening nut. The collet chuck 5
(tightening nut with collet) must assemble eas-
" symbol
ily. Should the collet chuck 5 be damaged, re-
place immediately.
Press the spindle lock button 9 and keep it
pressed. Possibly turn the spindle by hand until
the lock engages.
Unscrew the collet chuck 5.
Release the spindle lock button 9.
Clean the tool holding fixture and the collet 13
using a soft brush or by blowing out with com-
pressed air.
Tighten the collet chuck 5 again.
Do not tighten the tightening nut of the
collet chuck without a router bit in-
serted.
Mounting the Motor Unit
(see figure
To mount the motor unit 1, open the clamping
lever 10 and bring the two double arrows on the
motor unit 1 and the routing base 2 into align-
ment. Push the drive unit 1 into the routing
base 2 and turn the motor unit 1 in clockwise di-
rection until the "L" mark on the routing base 2
points against the line below the "
on the motor unit 1. Push the drive unit 1 into the
routing base 2.
After mounting is completed, position the
"L" mark of the routing base 2 in line with the
" " symbol on the motor unit 1 and lock the
clamping lever 10.
I After mounting, always check if the motor unit
is seated tightly in the routing base. The pre-
tension of the clamping lever can be changed
by readjusting the nut.
)
