Technical Data:
Span:
Body:
Weight without battery and receiver:
ESC / Motor controller:
Motor:
Impeller:
Recommended battery:
Assembling the plane
Please make sure that you are using the right screws (consider the length). See the instructions on the first page.
For the setup you need- next to the included screw driver- a pair of pliers.
1. Attach the servo horn (6) from the top side of the Elevator and fix it with the counterpart plate (7).
2. Install the adjuster onto the servo horn and fix it with the nut (recommend to take the 4th hole
3. Attach the elevator unit with BlueGlue onto the fuselage
4. Attach the fin onto the fuselage using BlueGlue.
880mm
880mm
Ca. 610g
30A Brushless
B2040 Brushless
64mm
11.1V (3S) 1800 - 2200mAh LiPo (not included)
