Horizontal and vertical leveling
Release the transport restraint, set the ON/OFF switch to On. The
horizontal laser line appears. The laser line scan be switched on
individually with the selection button.
The transport restraint must be released for horizontal and vertical
levelling. The laser lines flash and a signal sounds as soon as the
device is outside the automatic levelling range of 2,5°/ Position
thedevice such that it is within the levelling range.
Hand receiver mode
(optional: working with the laser receiver)
Use a laser receiver (optional) to carry out levelling at great
distances or when the laser lines are no longer visible. To work
with a laser receiver, switch the laser to hand-held receiver mode
by keeping button 6 (handheld receiver mode on/off) pressed.
The lser lines will now pulsate with high frequency, making the
laser lines darker. The laser receiver van detect these pulsating
laser lines.
Observe the laser receiver's operating instructions for lasers
A: Receiver area
B: Laser position indicator
C: Battery indicator
D: On/Off button
E: Rough and fine adjustment
F: Lever air-bubbles
G: Battery compartiment
H: Lampe de contrôle rouge
I: Rod clamb
J: Audiosignal On/Off
A
B
C
D
E
F
G
I
H
J
