Infl atable Boat
User's Manual
•
Construction Category D - "Internal Waterways" under Directive No. 94/25/EC of the European Parliament
and the European Committee.
•
A recreational vessel designed for use on internal waterways with an expected wind strength reaching Grade
4 on the Beaufort Scale inclusive and a determining wave height of up to 0.3 metres inclusive, with occasio-
nal waves up to 0.5 metres of height caused e.g. by vessels passing by.
•
The boat has been manufactured in compliance with the EN ISO 6185-1 Standard, Category II.
•
Related standards: EN ISO 10087, EN ISO 10240, EN ISO 14945.
Table of Contents:
Dear Customer,
This manual will help you to easily and safely master your vessel.
It contains a detailed description of the vessel, the supplied or built-in
equipment, its sets as well as information about its control and mainte-
nance. Please read it carefully, thereby getting to know the boat before
actually using it.
If this is your fi rst vessel or you have changed the type of vessel and
do not know this type well, please get acquainted with its maintenance
and control prior to your fi rst individual use of the vessel so that it is safe
and comfortable.
Your dealer or the National Yacht Federation or club will recommend you
appropriate training courses or qualifi ed instructors.
Please store this manual in a safe place and hand it over to the new
owner should you sell the vessel.
1. Table of Specifications
(Dimensions When Infl ated)
Length (cm)
Width (cm)
Peripheral cylinder diameter (cm)
Number of air chambers
Maximum operational pressure
Load (kg)
Weight (kg)
Max. engine power (kW)
Max. engine weight (kg)
Maximum number of people
Dimensions - packed in carry bag (cm)
Package dimensions (cm)
Draught (cm)
The highest anchor above surface (cm)
2. Technical Description
1. Side tube
2. Bottom
3. PUSH/PUSH valve which allows infl ation/defl ation, pressu-
re control and measurement by pressure gauge
4. Relief valve
5. Yellow "WARNING" label
6. Manufacturer's label
7. Bow deck
8. Flexible rope to hold luggage
9. Cushioned seat
8
RUBY
VERSION 4/2016
0,02 MPa [0,2 Bar/3 PSI]
10. Seat mount bracket
11. Bolt and plastic nut (see Detail A)
12. Safety rope tie-down
13. Safety rope
14. Anchor rope
15. Tube railing
16. Flexible rope with locks
17. D-ring holder
18. Paddle holder
19. Outboard mount transom
20. Transom holder
21. Blanket with fl exible rope (Detail B)
22. Blanket mount (D-ring holder)
23. Battery fi xing strap holder
GB
430
108
31
3
370
23
28
3
65 × 42 × 30
76 x 50 x 34
20
50
Page 8
8
9
9
9
10
10
10
10
10
10
11
