4.2 Operation
As all relevant data appears on the display at the same time, operation is essentially
restricted to simply selecting other sensors or additional weather data by lightly touching
the corresponding display field.
The display is divided into the display field and the menu line (device main menu dis-
played):
MIN MAX RESET
In normal mode the following functions can be accessed by touching the corresponding
fields on the display:
INDOOR: Toggle between displaying the temperature and the dew
point ("DEWPOINT")
OUTDOOR:
Toggle between displaying the temperature, the dew point
and the wind chill temperature
HUMIDITY: No function
SENSOR: Toggle between the external sensors:
1...8:
No display: HM-WDS100-C6-O
RAIN: Toggle between the total rainfall since the last reset ("total"),
rainfall for the current hour ("current 1h"), the last hour
("1h"), the current day ("current 24h") and the previous day
("24h"); hourly values recorded at 30 minutes past the hour;
daily values at 07:30 on the day in question
SUNSHINE DURATION: Toggle between hours of sunshine for the current day ("h/day")
and the total hours of sunshine since the last reset ("h")
TIME/DATE: No function
WIND: Toggle the numerical display between wind velocity in
km/h, m/s, mph and wind direction in degrees
AIR PRESSURE: Toggle the display of barometric pressure between the
pressure measured at the location ("absolute") and the
pressure at sea level calculated from that measured value
("relative")
HISTORY:
Toggle the trend indicator for the last 24 hours between
the barometric pressure, inside temperature and outside
temperature (of the sensor shown); refer also to point 26
on page 46
WEATHER SYMBOL FIELD: No function
54
CFG
HM-WDS10-TH-O, HM-WDS30-T-O or
HM-WDS40-TH-I
Main menu functions
MIN: Call minimum values
When "MIN" is touched, the minimum values for each type of data are shown
in the corresponding display fields. Touch the relevant field (temperature,
humidity, etc.) and the time stamp (date, time) of when the minimum value
occurred is shown at the right of the menu line.
Touch "MIN" again to return to the main menu and reinstate the standard
display of data.
MAX: Call maximum values
When "MAX" is touched, the maximum values for each type of data
are shown in the corresponding display fields. Touch the relevant field
(temperature, humidity, etc.) and the time stamp (date, time) of when the
maximum value occurred is shown at the right of the menu line.
Touch "MAX" again to return to the main menu and reinstate the standard
display of data.
RESET: Reset certain values
This menu has three submenus for resetting the total hours of sunshine
("SUN"), the rainfall ("RAIN") or the MIN-MAX memory ("MIN-MAX"):
Touch "RESET". The first RESET menu appears:
RESET RAIN
Touch "RESET" on the left repeatedly to select the required option and then
touch "OK". The corresponding data is now deleted and the main menu and
standard display of data are reinstated automatically.
However, if you do not want to delete any data, wait until the device returns to
the main menu. In this case, no data is deleted.
CFG: Call the configuration menu
OK
