4

Operation

Once the wireless sensors have been installed and the base unit has been started up,
data from the wireless sensors does not immediately appear on the base unit's display.
As every sensor has an individual serial number, each one must be registered with the
base unit separately.
The advantage of this approach is that data is only recorded from sensors that have
been specifically registered, not from any sensors belonging to a different, neighbouring
system, for example, not even after a restart.
Please note!
If no input area of the menu line is touched for around 5 s when making en-
tries, the device returns to the main menu automatically (and incorporates/sa-
ves any settings that have been made). Therefore, once you have made an entry, wait
until the main menu appears again. In the same way, you can also exit a menu each
time you have made an adjustment. Just touch the relevant input areas lightly, do not
press down on them hard. Do not use objects to press or tap the display. Once inside
a menu, touching and keeping your finger on an adjustment area allows you to adjust
values faster, as the system will continue to scroll through the possible
options without you having to keep touching the adjustment area over and over again.
4.1

Teaching-in/Deleting external sensors

A maximum of nine BidCoS -compatible external sensors can be registered with the
TM
system.
Memory slots 1 to 8 are reserved for the sensors HM-WDS40-TH-I (IT),
HM-WDS30-T-O (ITC), and HM-WDS10-TH-O (OTH) sensors.
Memory slot 9 is reserved for the HM-WDS100-C6-O combination sensor.
If there are several sensors of the WDS10, WDS30, or WDS40 types, we recommend
that the batteries are first removed from all sensors in order to ensure the sensors are
assigned uniquely.
Teaching-in
- Touch "CFG" in the menu line.
- The following appears:
NEXT CLEANING
- Touch "NEXT" and the following appears:
NEXT SENSOR
52
ENTER
ENTER
- Touch "ENTER" and the following appears:
SENSOR NO 1
- Touch "SENSOR" repeatedly to select the memory slot where the desired sensor is to
be saved. Please note that the HM-WDS100-C6-O can only be saved to the "COMBI-
SENSOR" memory slot.
- Then select "ADD" and the following appears (example for sensor 1):
SENSOR NO 1 - - SYNC
- The desired sensor now needs to be taught-in. To do this, insert the batteries in the
corresponding sensor and press its teach-in button. If "USED" appears in under one
second, the sensor has been taught-in correctly.
Data from the HM-WDS100-C6-O appears automatically (after a maximum of 6 minu-
tes) in the corresponding areas of the display; data from the other sensors appears as
per the memory slot selected in the "OUTDOOR" display field ("Sensor" field).
Identification of assigned memory slots
Memory slots that have already been assigned are identified by "USED" after the memo-
ry slot number.
However, this label does not indicate whether the corresponding sensor is actually
active or not. This will only become apparent if no data is provided or out-of-date
information is supplied when the sensor is selected and the reception indicator in the
"OUTDOOR" field is active.
Deleting a sensor's assignment
If necessary, a sensor's serial number can be deleted from the sensor memory.
- First proceed as described under "Teaching-in", then select the desired sensor and,
instead of touching "ADD", touch the "DEL" option.
- "USED" is deleted from after the sensor number, making the memory slot available for
registering a different sensor.
Tip for starting up sensors
In order to start sensors up properly, they can first be activated in the vicinity
of the weather station.
However, there must be at least 1 m between the sensor and the weather station
in order to prevent malfunctions.
ADD DEL
ADD DEL
53
