Warning: Don't mount the Singletrailer to carbon
or other lightweight construction seat posts.
5. Attaching the trailer to the bike: The quick-
release of the cardan joint must be open and
the coupling parts need to be clean. The cardan
joint is pushed over the coupling until it is
completely plugged in (the cardan joint nearly
contacts the seat post coupling now). The easi-
est this can be done is if the trailer stands on
its stand and the bicycle is led to the coupling
with one hand, while the other hand aligns
the coupling to the bicycle. Make sure that the
Singletrailer hangs straight behind the bike.
Proceed as follow:
a) Always stick the fastening bolt through the
coupling.
b) The quick-release fastener needs to be attached
securely and closed accurately.
c) Always secure with the safety rope! This should
be attached to the frame and not to the seat
post. Thus, also a possible break of the seat post
can be secured. Depending upon frame size and
-design the safety rope may be too long, in that
case simply wind it two or three times around
the seattube.
5. a)

OPERATION

The maximum additional load is 25kg. Please
consider following points for the usage:
➔ Never transport a child, without fastening the
5-point-seat belts. All belts can individually be
adjusted in length, and the shoulder belts are
additionally adjustable in height over the three
yellow transverse belts in the backrest. Lead
the shoulder belts always under the transverse
belt out, which lies closely above the shoulders
of your child.
➔ Despite the high safety level, your child should
always wear a helmet.
➔ Remember that your child hardly moves in the
trailer and therefore can cool down fast. You
should always carry weather specific clothing
in order to prevent your child from cooling down.
➔ On the bottom is a small mesh hole, which
serves as water and dirt drain as well as
permanent ventilation. Thus, the net should
never be covered completely.
5. c)
➔ All screws of the Singletrailer are secured
with stop nuts or screw locking. Nevertheless,
check regularly the tightness of all screws.
Also spokes should be examined regularly and
readjusted if necessary.
➔ The tension in the seat and in the backrest
can be adjusted individually with four screws
behind and underneath the seat. Please do
not overdraw, since otherwise unnecessary
forces impact the Singletrailer.
➔ Also the tension in side and bottom parts,
if diminishing over time, can be retightened
by the velcro fasteners, which fix the cover
to the frame.
➔ Make sure the stand hook is fully engaged.
Important: It is important that the wheel
engages completely and you cannot pull it out!
COVERS
There are four cover options:
1. Open: The net-cover is rolled up and put behind
the backrest. The window-cover is likewise rolled
up (make sure that the front rubber bands look
laterally outward) and fastened with the rubber
bands at the side of the trailer by pushbutton.
(shown with sun cover)
Warning: We do not recommend to use the cover
without the mesh cover option.
2. Mesh-cover: This is ideal in good weather condi-
tions and during fast riding. The child gets much
fresh air and is nevertheless optimally protect-
ed. The window cover is rolled up and stowed
away on the trailer. Close the push-buttons top
and bottom at the deck as well as the velcro
fastener at the dirt protection.
3. Rain-cover: The mesh-cover is rolled up and
stored behind the backrest, the window-cover
is closed. Close the pushbuttons top and bottom
at the deck as well as the velcro fastener at
the spraying protection. That way the trailer
is rainproof, however not waterproof. Through
the different frame junctions little water can
get inside the Singletrailer. it drains through the
mesh section in the bottom.
4. Sun-cover: (also in combination with window-
and net-cover) Close the pushbuttons top and
bottom as well as the elastic band in the middle
of the sun-cover (in front and in the middle it
encloses the drawbar). Now fix the window-
cover with the elastic bands in the pushbuttons
of the sun-cover.
