1
A
4
5
6
B
7
Buttons
■ From the main screen:
A
Opens.the.basic.menu;
■ When in a menu:
Return.one.level.in.the.menu-
structure;
■ In SHIFT mode:
Opens the advanced
menu.
B
Switch.between.AUTO.mode.
and.MANUAL.operation
■ When in a menu:
C
Confirm.a.setting.or.
selection;
■ From the main screen:
Activates SHIFT mode.
■ From the main screen:
D
Increase the ventilation
airflow;
■ When in a menu:
Browse through the menu
Increase values.
C
■ From the main screen:
E
■ When in a menu:
Display
■ Text;
1
■ Time;
■ Value.
■ Status;
2
■ Shows the start time, end time or
duration.
3
Air.flow.indication
4
Temperature.profile.indication
5
ComfoCool.symbol
6
Bypass.symbol
■ Air.flow.in/out.status.symbol.;
7
■ ComfoHood.symbol.
D
2
3
E
Decrease the ventilation
airflow
Browse through the menu
Decrease values
21
