Technical data

TP 3500 CC Re-
Mains voltage
mote
Mains voltage tolerance
Mains frequency
Mains fuse protection
Primary cont. power (100% duty cycle)
Mains connection
Primary continuous current
at 220 A / 28,8 V secondary
No load power
Cos phi
Efficiency
Welding current range
Welding power at
Apparent power at
Max. welding voltage at 350 A
Open circuit voltage
Degree of protection
Type of cooling
Insulation class
Marks of conformity
Safety symbols
Dimensions l x w x h
Weight
Overvoltage category
Pollution level according to IEC60664
Ventilation capacity
1)
connected to public grid at 230/400 V and 50 Hz
2)
d.c. = Duty cycle

ROB TSt interface

Marks of conformity
Dimensions l x w x h
Weight
1)
at 350 A
at 220 A / 28,8 V
at 150 A / 40,0 V
10 min / 40 °C (104 °F)
10 min / 40 °C (104 °F)
10 min / 40 °C (104 °F)
10 min / 40 °C (104 °F)
10 min / 40 °C (104 °F)
10 min / 40 °C (104 °F)
10 min / 40 °C (104 °F)
10 min / 40 °C (104 °F)
3 x 200 | 230 | 240 | 380 | 400 | 460 V
32 A slow-blow
Restrictions possible
28,2 | 25,4 | 24,5 | 17,5 | 16,8 | 15,0 A
109 | 130 | 140 | 289 | 315 | 410 VA
2)
35 % d.c. 350 A / 34,0 V
2)
60 % d.c. 280 A / 31,2 V
2)
100 % d.c. 220 A / 28,8 V
2)
100 % d.c. 150 A / 40,0 V
2)
35 % d.c.
2)
60 % d.c.
2)
100 % d.c.
2)
100 % d.c.
40,7 | 47,2 | 47,3 | 40,8 | 43,1 | 47,2 V
500 x 190 x 380 mm
19.68 x 7.48 x 14.96 in.
20,1 kg (44.3 lb.)
approx. 6 m³ / minute
160 x 90 x 58 mm
+/- 10 %
50/60 Hz
12,2 kVA
0.99
87 %
89 %
10 - 350 A
19,9 kVA
15,5 kVA
11,3 kVA
11,0 kVA
89 V
IP 23
AF
B
CE
S
III
3
CE
1.05 kg
71
