These operating instructions are an integral part of this product. They contain important information and safety notes,
and should therefore be kept in a safe place at all times. Be sure to pass them on to the new owner if you ever dispose of the
product.
1. S N
AFETY OTES
!
Read the instructions before using the controller
!
Avoid heat build-up
Provide unobstructed air circulation round the controller
!
Do not connect the flight battery with reversed polarity
Connecting the battery leads with reversed polarity will instantly wreck the controller
For this reason: • red wire to the POSITIVE terminal (+)
• black wire to the NEGATIVE terminal (-)
!
When soldering or working on the motor or controller
Always disconnect the battery (short-circuit / injury hazard)
!
When testing and running the power system
Do not run the motor while holding it in your hand; always secure the model firmly. Check that there is adequate space
for the propeller to rotate. Remove all objects from the area around the propeller which could be sucked in or blown away
(clothing, paper etc.). Never stand in the rotational plane of the propeller (injury hazard).
2. S :
PECIFICATION
Type Idem no.
BL-40 SD # 7 2234
3. P
ROGRAMMABLE
1. Brake Setting: Enabled / Disabled
2. Battery Type: Lipo / NiMH
3. Low Voltage Protection Mode(Cut-Off Mode): Soft Cut-Off (Gradually reduce the output power) /Cut-Off (Immediately stop
the output power)
4. Low Voltage Protection Threshold(Cut-Off Threshold): Low / Medium / High
1) For lithium battery, the battery cell number is calculated automatically. Low / medium / high cutoff voltage for each cell is:
2.85V/3.15V/3.3V. For example: For a 3S Lipo, when "Medium" cutoff threshold is set, the cut-off voltage will be:
3.15*3=9.45V.
2) For NiMH battery, low / medium / high cutoff voltages are 0%/50%/65% of the startup voltage (i.e. the initial voltage of
battery pack), and 0% means the low voltage cut-off function is disabled. For example: For a 10 cells NiMH battery, fully
charged voltage is 1.44*6=8.64V, when "Medium" cut-off threshold is set, the cut-off voltage will be:8.64*50%=4.32V.
5. Startup Normal /Soft /Super-Soft (300ms / 1.5s / 3s)
Normal mode is suitable for fixed-wing aircraft. Soft or Super-soft modes are suitable for helicopters. The initial acceleration of
the Soft and Super-Soft modes are slower, it takes 1.5 second for Soft startup or 3 seconds for Super-Soft startup from initial
throttle advance to full throttle. If the throttle is completely closed (throttle stick moved to bottom position) and opened again
(throttle stick moved to top position) within 3 seconds after the first startup, the re-startup will be temporarily changed to
MULTIPLEX Modellsport GmbH & Co.KG • Westliche Gewerbestraße 1 • D-75015 Bretten • www.multiplex-rc.de
Operating instructions
MULTIcont BL-40 SD
Cont. Current Burst Current
(A) (>10s)
40A 55A
I :
TEMS
Battery cell Weight
NiXX/Lipo (g)
5-12Ni \ 2-3 43
Lipo
BEC Size (mm)
Output W*L*H Program
5V/ 3A 65 x 25 x 12
Page 1/4
User
yes
