9. Changing stroke / 10. LED Function

9. Changing stroke

The dispenser can be set to dispense a single, double or triple dosage. If set for multiple dosage the dis-
penser will only operate as long as a hand is present. If the hand is removed it will complete the current
activation and stop the dispenser.
The dispenser is supplied set to single stroke as standard.
With the faceshield open press the tab (left hand side) to increase the stroke
The LED will flash amber when the tab is pressed correctly.

10. LED Function

Underneath the faceshield there is an LED which lights green, red and amber.
24
Pressing the tab Amber flash
1st time 2 flashes
2nd time 3 flashes
3rd time 1 flash
Colour Explaination
RED (solid) Faceshield open/not closed correctly
RED (Flashing) Batteries low
Green Unit dispensing
Amber Stroke selection (based on number of flashes)
Stroke
2 stroke
3 stroke
Returns to 1 stroke
