When charging the battery alone
< EC-E6000/BT-E6000/BT-E6001/BT-E6010 >
1.
Attach the adapter to the charging plug.
2.
Plug the charger's power plug into the outlet.
3.
Plug the adapter into the battery's charging port.
* When inserting the adapter into the charging port,
hold the charging plug so it is facing down toward
the adapter. Do not insert the charging plug upward
into the adapter.
* Charge the batteries on a flat surface indoors.
Charging plug
< BT-E6000/BT-E6001 >
Adapter
Charging plug
< BT-E6010 >
Charging plug
Adapter
11
Adapter
Battery
Charging port
Battery
Charging port
