Specifications
Input voltage
Max. pulling force
Power
Nominal torque
Standby consumption
Input accessories
Max. door weight
Motor
Type
Voltage
Noise level
Drive mechanism
Length of travel
Speed
Lighting
Safety
Electronically
Electrically
Limit switch adjustment
Dimensions
Length (overall)
Required clearance height
Suspended weight
Radio receiver
Memory
Operating frequency
Battery
16
Spare parts / Warranty
Please refer to www.chamberlain.eu or contact your local dealer.
Also refer to the available Warranty Book.
17
Accessory
(optional)
1. TX4RUNI 4-channel remote control
2. 128REV 2-channell wireless wall control
3. 747REV keypad
4. 75REV illuminated push button
5. 771REV safety photocells
(Door reverses automatically without touching an
obstacle)
6. 1REV external quick release
230-240 V 50 Hz
500 N
80 Watt
3.0 Nm
0,8 Watt
24 V / 300 mA
60 kg
worm gear type
24 V
55 dB
2.63 m
10 cm /sec
LED 1W
automatic force adjustment
thermal fuse in transformer
manually
3.14 m
min. 35 mm
10 kg
16 remote controls
433 MHz, 868 MHz
3 V, type CR2032 (10A20-WH)
18

Declaration of conformity

The manual consists of these operating instructions and
the declaration of conformity.
en 09/09
