Installation - SUEVIA 303 Bedienungsanleitung

The Heating Unit must be mounted in a horiz
Water circuit (min. ½", max. ¾") has to be installed according to the following sequence:
( 3) Install non-return valve
(18) Install water filter
( 7) Install automatic vent valve: it must be at the highest point of circuit in a
frost-protected-room (black knurled screw has to be in open position!)
( 6) Install pressure relief valve
(16) Install SUEVIA Drinking Bowls into the circuit (connected at the top and the bottom)
( 9) Install relief valve
(11) Install shut-off valve (for the main and the bypass-management)
(12) Install manual ventilation valve
(17) Install Flow control Mod. 309
(15) Mount non-return flap.
(19) Mount heating cable in the most frosty areas.
(13) Insulate pipes: minimum thickness 30 mm, heat conductivity
(14) Mount bite protection
(10) I nstall residual-current protective device.
System must be used with a separate 30 mA residual-current protective device (RCD)
Unit location:
Installation must be in a dry, frost- and draught-protected room and at an accessible height.
Pipe insulation:
IMPORTANT! Insulation of complete pipe system is indispensible,
-> minimum thickness 30 mm, heat conductivity
Water line has to be insulated against condensation of water and heat loss.
Water connection:
Water entrance ¾", circuit piping min. ½", max. ¾",
Water pressure has to be between min. 1 bar (14 psi) - max. 4 bar (58 psi)!
If water pressure is lower than recommended, install a pressure intensifier.
If water pressure is higher than recommended, install a pressure reducer valve.
Circuit length :
Length of the insulated water tube system incl. all return pipes should not exceed 200 m (
Circulation pump :
Circulation pump must run on positon 3.
Circulation pump has to be bled (see page 23).
The height difference between entry and return pipeline should not exceed 5 meters.
Functioning capability of Circulation pump has to be constantly checked!
Main Control Switch Position:
0 = OFF Circulation Pump and Heating are out of service
1 = ON Circulation Pump runs constantly, heating switches on automatically
Application field:
SUEVIA Heating Unit Mod. 303 / Mod. 300 is exclusively designed to keep water pipes
frost-free in stables for animals. It can only be used for warming up water, other liquids are
16
not allowed!

Installation

Install it only horizontally. Pay attention to the water flow direction!
ontal position on the wall!
0,04 / W .
mK
0,04 / W
mK
656
feet)
