HENSEL Studiotechnik Radio Flash Trigger and Power Control System RC/RF
When an exchange of the battery of the external Radio
Receiver is required, the red LED 9 turns on. Opening of the
battery compartment is done by means of a coin, inserted into
the lateral slot. The batteries can be removed from the clips
and exchanged by three new AA batteries under observation
of the polarity.
10
This product conforms to the radio standards ETSI EN300220
and FCC15.231.

Technical data

Technical Data
Type / Code No.
Sync socket:
Sync. voltage /
Sync. current
Switching ON/OFF
Channels:
Sync plug
Serial port:
Shutter time for
Synchronization:
Dimensions in cm
[inch] (width x length
x height)
Weight (no battery):
Weight (with battery):
Type of battery:
Battery life:
Range:
Frequency:
User Manual - Page 13 -
Transmitter
RC/RF-TS / 390
2,5 mm jack plug,
Mono
3 V /
< 1mA for 5 µs
------------------
4, selected by DIP- Switch
------------------
------------------
1/250 s
5,5 x 6,3 x 4,8
[2.2 x 2.5 x 1.9]
53 g
CR2, 3 V, 1pc.
1 - 2 years
> 40 m (131 feet) free visibility
433,92 MHz
Receiver
RC/RF-R / 388
------------------
< 60 V /
------------------
By applying Sync
voltage
6,3 mm jack plug,
plus pole front
Mini DIN
socket 8 pol.
6,5 x 3,7 x 14,1
[2.6 x 1.5 x 5.6]
84 g
157 g
AA, 3 pcs.
approx. 6 months
