Battery
Reading of the battery charge level
To know the charge level, press and hold the charge button located above the battery. Please note
that the charge LED remains functional even if the battery is switched off (see below).
The 4 LEDs light up to indicate the corresponding charge level.
DISPLAY
Flash LED
Installing and using the battery
The e-bike has the battery located on the down tube of the frame (the battery is directly connected
to the controller box which is located under the battery).
Lift the battery above the frame down tube, align the position of the battery sliders, then place the
battery box inside the slot, make sure it fits snugly, then lock it tightly. Firmly fastening the battery,
use the key to lock the battery with the slider. (Fig.3.1~3.3)
BLUE
GREEN
RED
CHARGE LEVEL
100%
75%
50%
< 25% need to recharge
