• Remove the USB cable from your computer when you have finished using the
microphone. Depending on the operating system, connected USB devices must be
ejected/safely removed before disconnecting them from your computer. Refer to
the user manual for your OS. The LED indicator turns off when you disconnect the
microphone from your computer.
c) Using the microphone
Recording
• Move the INPUT switch (3) to the MIC position and the OUTPUT switch (5) to MONO
or STEREO.
• Speak into the USB microphone.
Recording and listening in real time
• Move the INPUT switch to the MIC position.
• Move the OUTPUT switch to MONITOR and connect a pair of headphones (not
included) with a 3.5 mm jack plug to the OUTPUT socket (10).
• Speak into the USB microphone. You will hear yourself in real time via the
headphones. You can control the amplification using the MIC gain control (1).
Connecting and recording from an external device
• Move the INPUT switch to the AUX IN position and connect an external device such
as an external microphone (not included) with a 3.5 mm jack plug to the AUX IN
socket (2). If necessary, use the 6.3 mm to 3.5 mm adapter.
• Move the OUTPUT switch to MONO or STEREO and connect a pair of headphones
with a 3.5 mm jack plug to the OUTPUT socket.
• Play some music on your computer. You will hear the music on the headphones. You
can control the volume using the headphone VOLUME control (7).
• Speak/sing into the connected external microphone.
Connecting, recording and listening to an external source in real time.
• Move the INPUT switch to the AUX IN position and connect an external device such
as an external microphone (not included) to the AUX IN socket.
• Move the OUTPUT switch to MONITOR and connect a pair of headphones to the
OUTPUT socket.
• Play some music on your computer.
• Speak/sing into the connected external microphone.
• You will hear yourself in real time via the headphones. Adjust the volume of the
connected device using the AUX volume control (9).
Always connect an external device to the AUX IN socket when the INPUT
switch is in the AUX IN position, as otherwise the USB microphone will not
work, even if the LED indicator is blue. Only the external connected device
will be used for recording.
To connect another source, e.g. a mobile phone, you can use the 3.5 mm
stereo audio cable included with the product. Insert the jack plug into the
AUX IN socket on the USB microphone and then connect the other end of
the cable to the audio input on your mobile phone.
Use the Cinch to 3.5 mm adapter cable included with the product to connect
a playback device with Cinch audio connections.

Maintenance and cleaning

• Never use aggressive and abrasive detergents, rubbing alcohol or other chemical
solutions, as these could damage the casing or even impair the functioning of the
product.
• The product does not require maintenance except for occasional cleaning. Under
no circumstances should you service any of the components in the interior of the
device, therefore never open it.
• Remove the product from the power supply (USB port) and any connected devices
before cleaning.
• Use a soft, antistatic and lint-free cloth to clean the device. Dust can be easily
removed using a soft and clean long-haired brush.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste.
At the end of its service life, dispose of the product according to the
relevant statutory regulations.
You thus fulfil your statutory obligations and contribute to the protection of the
environment.

Technical data

Operating voltage............................ 5 V/DC, 500 mA
Frequency response ....................... 50 Hz - 18000 Hz
Sensitivity ......................................... -65 dB ±5 dB (at 1KHz 3.0V 680 Ω (0 dB=1 V/μbar)
Sound pressure level (SPL) ........... max. 120 dB
Directivity ......................................... Cardioid
Working principle ............................ Condenser microphone
Connection ....................................... USB 2.0
Supported operating systems ....... Windows
Operating conditions ...................... 5 to +55 °C, 20 - 80 % RH
Storage conditions.......................... 0 to +60 °C, 20 - 60 % RH
Dimensions (W x H x D).................. 65 x 160 x 58 mm (microphone)
Weight ............................................... approx. 468 g (microphone)
Frequency response
Directivity
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent the
technical status at the time of printing.
© Copyright 2015 by Conrad Electronic SE.
® XP (Home, Pro with SP1, SP2, SP3, 32-bit),
Vista (32/64-bit), 7 (32/64-bit), 8.0 (32/64-bit),
8.1 (32/64-bit), Mac OS X 10.6x (with USB support)
