PROPAC
IMPORTAnT InFORMATIOn!
1. Read the Multiblitz Profilux Plus / X10 „User's Guide" thoroughly before
operating a Propac battery pack together with a Profilux Plus / X10 unit.
2. Only Profilux Plus / X10 units are to be operated on a Propac battery back.
3. A 150 W halogen tube (Code: PACHAL) is included in the scope of supply.
To ensure a correct rendition of color for the modeling light, we highly
recommend using this halogen tube in your Profilux Plus / X10 unit when it
is being operated on a Propac battery pack.During battery operation with
halogen tube PACHAL, the supplied pyrex-dome (Code: PLUSKLA / LUKLA-1)
must be attached to the internal reflector of the Profilux Plus / X10 unit used.
4. It is absolutely necessary to exchange the halogen tube when switching
from battery operation to 220–240 V mains operation.
Battery operation with Propac-1 or -2 to 220-240 V mains operation:
Exchange the 100 V–130 V halogen tube PACHAL with the 220–240 V
tubes PROHAL, LUHAL 2 or LUHAL 3, depending on the units´
performance class.
It is not necessary to exchange halogen tubes when switching from
battery operation to 100-130 V mains operation and vice versa,
because the recommended tube for battery operation and 100-130 V
mains operation (Code: PACHAL) is designated for both operating modes.
5. To protect the batteries (deep discharge protection) against permanent deep
discharges, which can be unfavourable for the Propac, the connected Profilux
Plus units units will automatically switch off as soon as a critical state of
charge is reached:
QuICk START
1. Place the supplied 150 W halogen tube (Code: PACHAL) into the Profilux
Plus / X10 unit that will be operated on the Propac.
2. Attach the supplied pyrex-dome (Code: PLUSKLA / LUKLA-1) to the
internal reflector of the unit.
3. Use the supplied lamp cable (Code: PACNET) to connect the ready to
use Profilux Plus unit with either lamp head socket I or II of the Propac.
4. Proceed as described in steps 1 to 3 if you like to connect a second unit
to the Propac.
5. Plug the supplied battery cable into one of the lamp sockets to activate
the battery and turn on the Propac using its "On-Off" switch, the battery
level is displayed. The Profilux Plus unit is in "stand-by" mode, the „I-0"
button glows red.
- The digital display of the Profilux Plus / X10 changes between indicating the
selected output and „LO" (for „Low"), the very left of the four green LEDs
on the Propac starts blinking and an acoustic signal sounds.
- Now, only a few more flashes can be fired before the unit switches off.
- A soon as the red LED of the battery level indicator starts blinking,
the Propac should be turned off and recharged promptly.
6. During recharge, no Profilux Plus units can be operated on a Propac.
7. If a Propac is only used occasionally or not in use for longer time period,
it always should be stored fully charged. We recommend to fully charge
the Propac at least every 3 months.
8. When turning off the Propac it should not be switched on again directly,
wait until the battery level indicator has entirely gone out. If you switch on
directly after switching off, the deep discharge protection will stay active
and the two lamp sockets remain locked.
6. The Propac can be recharged using the supplied multi-voltage charger
(Code: PACLA). Plug the charger into a wall outlet (you might need the
separately available travel plug adapter TRAPLUG, depending on the
country you are in). Connect the charger to lamp head socket I of the
Propac, marked with "Charge". The charging activity is displayed via the
very right green LED of the Propacs´ battery level indicator.
7. As soon as the Propac is fully charged the multi-voltage chargers´ LED
changes its´color from red to green. Charging time for Propac 1 = 4 hrs.
Charging time for Propac 2 = 4,5 hrs.
8. Recharging the Propacs for ten hrs will result in a 25% gain of flash
capacity. After ten hours of charging, the Propac and the multi-voltage
charger will automatically switch off.
