Betriebsanleitung | Deutsch
illustration not to scale
Darstellung nicht maßstabsgetreu
weight*
Eigengewicht*
max. length
Max. Länge
max. height
Max. Höhe
* without tripod
* ohne Stativ
weight*
Eigengewicht*
max. length
Max. Länge
max. height
Max. Höhe
* without tripod
* ohne Stativ
product name
Bezeichnung
Pixy crane, version 3
PIXY Kransystem, Version 3
Qty.
Anzahl
1
1
18 kg / 40 lb
1
5.8 m / 19'
1
5 m / 16'5"
1
1
2
1
1
1
1
1
Pixy crane, version 4
PIXY Kransystem, Version 4
Qty.
Anzahl
1
1
22 kg / 49 lb
1
7.1 m / 23'8"
1
6 m / 19'8"
1
1
2
1
1
1
1
1
2
1
Seite ‑ 6
consisting of
bestehend aus
Pixy Tripod
Central pivot section
lifting rod Pixy
carrier tube
rear tube
weight bar
extention tube
Remote Mount
base bracing
Bracing extention
for V3/5/7
Balance rod 1.6 m / 5'3" Parallelogramm 1,6 m
Balance rod 1.3 m / 4'3" Parallelogramm 1,3 m
consisting of
bestehend aus
Pixy Tripod
Central pivot section
lifting rod Pixy
carrier tube
rear tube
weight bar
extention tube
extention tube for
bracing
Remote Mount
base bracing
Bracing cable V4
Balance rod 1.6 m / 5'3" Parallelogramm 1,6 m
Balance rod 1.3 m / 4'3" Parallelogramm 1,3 m
Balance rod support
code no.
Art.-Nr.
139712
code no.
Art.-Nr.
Pixy Stativ
183892
Mittelteil PIXY Kran
143788
Hebelstange Pixy
137363
Trägerrohr
143777
Endrohr
137097
Gewichtsstange
142297
Verlängerung
137096
Galgen
137098
Basisabspannung
137106
Abspannungs-
157242
verlängerung für V3/5/7
142404
142405
139711
code no.
Art.-Nr.
Pixy Stativ
183892
Mittelteil PIXY Kran
143788
Hebelstange Pixy
137363
Trägerrohr
143777
Endrohr
137097
Gewichtsstange
142297
Verlängerung
137096
Verlängerung für
137342
Abstützung
Galgen
137098
Basisabspannung
137106
Abspannung V4
138383
142404
142405
Parallelogrammstütze
142406
für Stange
