Betriebsanleitung | Deutsch
illustration not to scale
Darstellung nicht maßstabsgetreu
weight*
Eigengewicht*
max. length
Max. Länge
max. height
Max. Höhe
* without tripod
* ohne Stativ
weight*
Eigengewicht*
max. length
Max. Länge
max. height
Max. Höhe
* without tripod
* ohne Stativ
product name
Bezeichnung
Pixy crane, version 2 compact
PIXY Kransystem, Version 2 Kompakt
Qty.
Anzahl
1
16 kg / 35 lb
1
4.5 m / 14'9"
4 m / 13'1"
1
1
1
1
4
1
1
1
Pixy crane, version 3 compact
PIXY Kransystem, Version 3 Kompakt
Qty.
Anzahl
1
18 kg / 40 lb
1
5.8 m / 19'
5 m / 16'5"
1
1
1
1
6
1
1
1
1
1
Seite ‑ 9
consisting of
bestehend aus
Pixy Tripod
Central pivot section
lifting rod Pixy
carrier tube compact
rear tube compact
weight bar
extention tube compact
Remote Mount
base bracing
Balance rod compact
1.6 m / 5'3"
consisting of
bestehend aus
Pixy Tripod
Central pivot section
lifting rod Pixy
carrier tube compact
rear tube compact
weight bar
extention tube compact
Remote Mount
base bracing
Bracing extention
for V3/5/7
Balance rod compact
1.6 m / 5'3"
Balance rod compact
1.3 m / 4'3"
Pixy Stativ
Mittelteil PIXY Kran
Hebelstange Pixy
Trägerrohr compact
Endrohr compact
Gewichtsstange
Verlängerung compact
Galgen
Basisabspannung
Parallelogramm Stange
compact 1,6 m
Pixy Stativ
Mittelteil PIXY Kran
Hebelstange Pixy
Trägerrohr compact
Endrohr compact
Gewichtsstange
Verlängerung compact
Galgen
Basisabspannung
Abspannungs-
verlängerung für V3/5/7
Parallelogramm Stange
compact 1,6 m
Parallelogramm
compact 1,3 m
code no.
Art.-Nr.
146676
code no.
Art.-Nr.
183892
143788
137363
146203
146217
142297
146168
137098
137106
146128
146677
code no.
Art.-Nr.
183892
143788
137363
146203
146217
142297
146168
137098
137106
157242
146128
146205
