Betriebsanleitung | Deutsch
5.
Lieferumfang
Das PIXY Kransystem ist für die individuelle Ausrichtung auf den jeweiligen Einsatzzweck und Anfor‑
derung konzeptioniert worden. Durch die Vielzahl an Einzelkomponenten gibt es nahezu unbegrenzte
Kombinationsmöglichkeiten und das System lässt sich je nach Wunsch für beinahe jede Anwendung
zusammenstellen.
Die folgenden Versionen sind als Pakete erhältlich und decken die häufigsten Anforderungen ab. Darü‑
ber hinaus ist eine individuelle Zusammenstellung der Komponenten möglich.
illustration not to scale
Darstellung nicht maßstabsgetreu
weight*
Eigengewicht*
max. length
Max. Länge
max. height
Max. Höhe
* without tripod
* ohne Stativ
weight*
Eigengewicht*
max. length
Max. Länge
max. height
Max. Höhe
* without tripod
* ohne Stativ
product name
Bezeichnung
Pixy crane, version 1
PIXY Kransystem, Version 1
Qty.
Anzahl
1
1
9 kg / 20 lb
1
1.9 m / 6'3"
1
2.5 m / 8'2"
1
Pixy crane, version 2
PIXY Kransystem, Version 2
Qty.
Anzahl
1
1
16 kg / 35 lb
1
4.5 m / 14'9"
1
4 m / 13'1"
1
1
1
1
1
1
Seite ‑ 5
consisting of
bestehend aus
Pixy Tripod
Central pivot section
carrier tube
weight bar
Remote Mount
consisting of
bestehend aus
Pixy Tripod
Central pivot section
lifting rod Pixy
carrier tube
rear tube
weight bar
extention tube
Remote Mount
base bracing
Balance rod 1.6 m / 5'3" Parallelogramm 1,6 m
Pixy Stativ
Mittelteil PIXY Kran
Trägerrohr
Gewichtsstange
Galgen
Pixy Stativ
Mittelteil PIXY Kran
Hebelstange Pixy
Trägerrohr
Endrohr
Gewichtsstange
Verlängerung
Galgen
Basisabspannung
code no.
Art.-Nr.
139714
code no.
Art.-Nr.
183892
143788
143777
142297
137098
139713
code no.
Art.-Nr.
183892
143788
137363
143777
137097
142297
137096
137098
137106
142404
