RF RxT SW2.4LE-IND
Montage- und Anschlussanleitung / Funk-Empfänger
Mounting and wiring instructions / Wireless receiver
Instructions de montage et de câblage / Récepteur radio
English
Technical data
General
Applied standards EN 300 328; EN 301 489-17; EN IEC 62368-1;
EN 60947-5-1; EN IEC 63000
Material Enclosure: polyamide, RAL 7035, UL94 V-0
Degree of protection IP20 (IEC/EN 60529)
Degree of pollution 2
U i 250 VAC
U imp 2.5 kV
Ambient temperature 0 °C ... +55 °C (operation)
-25 °C ... +85 °C (Transport and storage)
Mounting Quick fastening for standard rail
Teachable transmitters 1
Power supply
Extern
Ue 24 VDC ± 15 %
Ie < 60 mA
LED indicators Power Green: Power supply is switched on,
Red: Internal error
Battery foot switch
LED battery indicator Off: Foot switch offline.
Green: Battery 50 %–100 % charged.
Orange: Battery 20 %–50 % charged.
Flashing orange: Battery 5 %–20 % charged.
Flashing green: Battery charging.
Switching outputs
General
Number/type 5/relay contact – normally open (NO)
Connection type Screw connection with pull-through sleeve
(screw connection terminals)
0.14 ... 2.5 mm² / AWG 26 ... 14,
stripping length 8 mm / 0.3 in,
tightening torque 0.5 Nm ... 0.6 Nm
Switching current/
voltage 5 A / 250 VAC, 30 VDC (resistive load)
Mechanical life
>5x10 6 operations
K1..4
Mechanical life
>10x10 6 operations
VAL
Electrical life
>1x10 5 operations AC1
K1..4
Electrical life
>1x10 5 operations AC1
VAL
Shock resistance K1..4 1 g
Vibration resistance
K1..4 10...55 Hz, 1.5 mm, 2 g
Shock resistance VAL 7 g
Vibration resistance VAL 10 to 200 Hz, 2 g
Display LEDs
K1..4 and VAL
Radio interface
General
Frequency
Data rate
Channels
Type of modulation
Channel grid
Protocol
Transmission power
Wireless approvals
Function
Telegram rate
Synchronisation
after sleep mode
Note
Range
Antenna
LED Connect display
8 / 12
Off: relay not energised
Orange: relay energised
2400 - 2483.5 MHz
1 Mbps
40 (Adaptives Frequenzhopping)
GFSK (Gaussian Frequency Shift Keying)
2 MHz
SW2.4LE
max. 10 dBm (10mW)
EU: RED 2014/53/EU
USA: FCC-ID XK5-SW24LE
Canada: IC 5158A-SW24LE
Japan: ARIB STD-66: 204-650001
20 ms (bidirectional)
67 ms (typical), 110 ms (max)
Risk period 120 ms: After the risk period has
elapsed, the receiver switches to the
safe state (all relays de-energised).
max. 45 metres indoors
Only use antennas approved by steute.
Green: Radio connection established,
button on the foot switch pressed;
Orange: Radio connection established, button on
the foot switch not pressed;
Off: No radio connection;
Flashing red: Device is in pairing mode;
Red: Serious error. Servicing required.
