RF RxT SW2.4LE-IND
Montage- und Anschlussanleitung / Funk-Empfänger
Mounting and wiring instructions / Wireless receiver
Instructions de montage et de câblage / Récepteur radio
English
Additional product information
https://go.steute.com/im_rf_rxt_sw2.4le_ind
Use of the mounting and wiring instructions
All actions described in these instructions may only be performed by
qualified persons who have been trained and authorised by the
operating company.
1. Read and understand these mounting and wiring instructions.
2. Comply with the valid occupational safety and accident prevention
regulations.
3. Install and operate the device.
Selection and installation of devices and their integration in control
systems demand qualified knowledge of all the relevant laws, as well
as the normative requirements of the machine manufacturer. In case
of doubt, the German language version of these instructions shall
prevail.
Scope of delivery
Device, mounting and wiring instructions, packaging.
Intended use
The radio receiver is used to switch electrical consumers by means of
radio transmission.
Mounting and wiring
Mount the device on a standard DIN rail.
Safety
Do not use the device in conjunction with devices that directly or indi-
rectly serve health or life safety purposes or whose operation may
pose a risk to people, animals or property.
Radio operation
Transmission takes place on a frequency of 2.4 GHz. The receiver can
only be used in conjunction with the RF GF(S) (2) (XL) SW2.4LE-IND
transmitter.
Assignment of locations:
Location according to
EU 2014/53/EU (RED)
USA FCC
Canada IC
Design of wireless range
The radio signal is attenuated on the way from the transmitter to the
receiver. In addition, the radio signal is influenced by obstacles. The
degree of attenuation depends on the material of the obstacle.
The following tables serve as a guide.
Penetration of radio signals:
Material
wood, gypsum, glas uncoated
brick stone, press boards
armoured concrete
metal, aluminium lamination, water
Typical ranges:
Location
indoors (line of sight)
Antenna
Only use suitable antennas:
Device Antenna
SW2.4 RF magnet antenna 2.4 GHz
1 m
Mount the antenna on sheet metal. The sheet metal serves as an RF
counterweight. Minimum size of the sheet metal: 250 x 250 mm.
Pairing
See section »Pairing«.
Note
Modifications and alterations to the device are not permitted.
Maintenance
steute recommends routine maintenance as follows:
1 . Remove all dirt particles: Clean enclosure on the outside only. Clean
device in accordance with IP protection class. Clean with a soft cloth
and water or a mild detergent. Do not clean using compressed air.
2. Test the function.
Cleaning
- In case of damp cleaning: use water or mild, non-scratching,
non-chafing cleaners.
Clean enclosure on the outside only. Clean enclosure with household
cleaning agents. Do not use compressed air to clean.
Disposal
- Observe national, local and legal regulations concerning disposal.
- Recycle each material separately. Dispose of all batteries correctly.
2 / 12
Penetration
90...100 %
65...95 %
10...90 %
0...10 %
Wireless range
(approx.)
max. 45 m
Mat. No.
1186917
