SG-F20H
FORA COMPLETE D ESCRIPTION O FTHEOPERATION OFTHISUNITü PLEASE
REFER TO THE OPERATION MANUALS*
GENERAL
PoWer source:
AC 220
Power 80 w
consumption:
Dimensions: Width;
Height; 259 mm (10-3/16")
Depth; 373 mm (14-11/16")
Weight: 6.4 kg (14.2 lbs.)
AMPLIFIER SECTION
Continuous power 2 x 13 W/8 ohms, (DIN 45 324)
output;
Music power 2 x 25 W/8 ohms, (DIN 45 324)
output:
Peak music power 100 W/8
output:
Input sensitivity CD/AUX;
and input im-
pedance:
Loaded impedance: Speakers; 8 ohms
Headphones;
TUNER SECTION
Frequency range: FM; 87.5
MW;
LW; 148.5 - 285 kHz
I. Turnthe drumfullyinthedirection@shownin Fig.2 and
stretch its cord over the parts in the numerical order.
2. Thenturnthetuningcontrolshaftfully inthe direction@
shown in Fig. 2 and fix its pointer as shown in Fig. 2.
Pulley
(233)
SPECIFICATIONS
V, 50 Hz
365 mm (14-3/8")
ohms
300 mV/47 kohms
8-25 ohms
- 108 MHz
526.5 - 1606.5 kHz
STRINGING
3 Turns
Knob, Tuning Control
(214)
o
7
Pulley
(233)
Drum
(232)
10
Pul ley
(233)
CASSETTE DECK SECTION
Tape:
Compact cassette tape
Bias and erasure AC 90 kHz
system:
Tape speed:
4.76 cm/sec. (1-7/8 ips)
Heads: Playback; I
Record/PIayback;
VEraSe;I'
Motor:
DC motor;
TURNTABLE SECTION
Type:
Belt drive, semi automatic
Speed: 93-1/3 and 45 fpm
Motor:
DC motor
Arm/Cartridge:
Static balanced-straighttonearm with
magneticcartridge
Replacement
STY-155
styluS:
Specifications for this modelaresubject to change without
prior notice.
OF DIAL CORD
Dial
Dial Pointer
(211)
ley
(233)
Figure 2
I
2
cord Ass'y (204)
622mm
