iNsTRUCTiONs ON AsseMBlY AND Use
EN
CONGRATUlATiONs ON
PURCHAsiNG THis PRODUCT!
Please read these instructions carefully. The instructions are an integral
component of the product. Therefore, please store them and the packa-
ging carefully in case questions arise in the future. Please always include
these instructions when giving the product to a third party. This product
must be assembled by an adult. This product is not designed for indus-
trial use. The use of the product requires certain capabilities and skills.
Always adjust according to the age of the user and use for the purpose it
has been designed for.

TeCHNiCAl sPeCiFiCATiONs

Item: Punching Ball Profi XL
Item number: 74502
Adjustable height: 116 to 160 cm
Weight: 3.6 kg
If you have assembly problems or would like further information on the
product, we have all you need and more at http://www.hudora.de/ser-
vice/.

sAFeTY iNsTRUCTiONs

Please check that the equipment has no technical faults; in the case of
damage or lose connecting elements don't use the product anymore.
Adjustments to the product or use of non-original parts can lead to ac-
cidents. The set is not stable unless sufficient ballast is used. Before trai-
ning, please fill the set with sufficient sand and check stability. Before use
chose a location for training with sufficient space, so that no damage can
be caused to persons or other objects. We advise that the set is stored
in a dry and dark place. When necessary clean your set using a slightly
damp cloth. Moisture on the metal parts of the equipment can lead to rust
and should therefore be avoided. Boxing gloves of a suitable size should
always be worn during training.
iNsTRUCTiONs ON AsseMBlY
Step 1:
Remove all parts from the packaging. Next pump up the ball (10). To do
this screw the valve adapter (11) on to the pump and pierce the valve on
the ball. Pump until the ball is hard (not too hard otherwise it could burst.
If the ball is too hard boxing can become painful!) Remove the pump and
keep it safe, as the ball could lose pressure over time. If you wish to de-
flate the ball, simply pierce the valve using the valve adapter.
Step 2:
Next, screw the ball onto the telescopic tube (9). For best mounting, two
different screws should be used to fix the ball in place. For the lower
cross screw, make sure the inner tube is screwed in in such a way that
the borehole is completely open and the screw can penetrate easily. Fol-
lowing this, bolt the cross screw together with a cap nut and two lock
washers. Another smaller screw must then be screwed into the upper
hole.
Step 3:
Now it is time for the base: Is the plastic sleeve already on the spring
(7)? If not, first place it over the spring so that no hair or fingers can get
caught in the spring thread. Then place the metal plate with the hole (5)
in it over the pipe with the spring (7) as shown in the picture. Now insert
the guide sleeve (2) into the base (1) from above and push the tube with
the spring (7) through along with the metal disc (5). Mount another guide
sleeve (2) and a centering plate (4) before fixing the entire construction
with the Allen key (6).
Step 4:
A suitable key is provided to tighten the Allen screw. The screw has a type
of glue on the thread and is therefore more difficult to tighten. This is to
prevent it from becoming lose. If the screw is tightened often it can cause
wear and become unsafe, which would require the screw to be replaced.
Now place the standpipe (8) on top; it fits into the spring knob on the
spring pipe. Loosen the plastic thread on the support tube (8) by turning
it anti-clockwise. Then place the telescopic tube (9) into the support tube
(8). Fix the telescopic tube (9) in position by turning the plastic thread at-
tached to the support tube (8) in a clockwise direction so as to tighten it.
The middle of the ball can now be set to a height between 1160 and 1600
mm. There are markings 50 mm from the bottom end of the telescope
pipe. The pipe must not be lifted further than these markings, as the plas-
tic thread would then no longer be safe. Make sure that plastic thread is
screwed tight during use so that the ball cannot move on its own.
Step 5:
Now fill the base with sand and place the cap (3) on the opening. Make
sure that you only use the punch ball on surfaces which are not sensitive!
MAiNTeNANCe AND sTORAGe
Use a dry or damp cloth only to clean the product; do not use special
cleaning agents! Check the product for damage or traces of wear and tear
before and after each use. Do not make any structural changes. For your
own safety, please use original spare parts only. These can be sourced
from HUDORA. If parts become damaged or if sharp edges or corners
should develop, the product may not be used any more. If in any doubt,
please contact our service team (http://www.hudora.de/service/). Store
the product in a safe place where it is protected from the elements, can-
not be damaged, and cannot injure anyone.

DisPOsAl ADViCe

At the end of the product's life, please dispose of it at an appropriate coll-
ection point provided in your area. Local waste management companies
will be able to answer your questions on this.
seRViCe
We make every effort to deliver faultless products. If faults do arise howe-
ver, we put just as much effort into rectifying them. You can find numerous
information on the product, replacement parts, solutions to problems and
lost assembly manuals at http://www.hudora.de/service/.
