MOTOR
The motor «C» of your power-assisted bike is a brushless-type motor with mechanical reduction, which means you
can have high torque and less resistance (quieter motor). The A-weighted emission sound pressure level at the driver
ears is less than 70 dB(A). Motor power is limited to 250 W maximum.
BATTERY AND CHARGER
Battery properties and warranty
All batteries in our electric bikes use Lithium-Ion cell technology and have no memory effect. The battery can be
recharged at any time. There's no need to wait until it's completely discharged.
The battery should be recharged after each use.
Fully charge the battery before using it for the first time.
Battery
36 V / 17.5 Ah battery
630Wh
Your battery is guaranteed for 2 years or 500 charge and discharge cycles (1 cycle = 1 charge from 0% to 100% +
1 discharge from 100% to 0% or 1 cycle = 2 charges to 50%) subject to compliance with good conditions of use and
storage. Do not use a different charger from the one supplied by DECATHLON for this bike model. Using another
charger may damage the battery or cause serious incidents (sparks, fire).
Battery life
The battery life of the electric bike depends on numerous factors:
- The weight on the bike: Overloading the bicycle will reduce the battery life (panniers, baby carrier etc).
- Use: Based on the human effort put in when pedalling, the battery life will be shorter or longer.
- The type of route ridden: Battery life will drop when cycling uphill.
- Tyre pressure: Battery life will be better with tyres inflated between 1,2 and 2,5 bar.
- Outside temperature: Cold weather reduces battery life.
- The assistance mode used: It is advisable to switch to a lower assistance mode when the battery charge is
low.
- The selected transmission ratio: You need to be in the right gear on steep slopes to minimise the physical
effort you have to make as well as reduce the load on the motor.
Charger
Input: 100-240 V
Output: 42 V
