Wall mounting

The telephone can also be installed on a wall. You require two screws in order
to fix the telephone on a wall.
Feed the guide tabs (1) on the wall−mounting bracket (2) in the slots (3) on the
rear side of the telephone. Slide the wall bracket (2) 10 mm upwards until it
audibly snaps into place.
3
1
Warning: Ensure that there are no cables or pipes etc. under the surface of
the wall where you want to drill the holes.
Drill two holes whose distance apart corresponds to the bracket to be used,
insert the screws and allow them to project 5 mm from the wall.
Position the telephone on the bracket, fit the screws in the slots and slide the
telephone downwards a little.
3
2
