Warning!
Depending on the size of the room, heat requirement and
thermostat setting, rooms may overheat if the heating is not
controlled. This can be dangerous for people who are not
able to leave the room as it gets too hot.
5. Anti-Overheat
The heater is protected against overheating. If the air circu-
lation is impeded (e.g. by covering or blocking of the air
grille), the unit automatically switches off.
If this occurs, switch the heater off for a few minutes (turn
the switch to "0" or pull the plug out), so that the unit can
cool down sufficiently. Before switching the unit on again,
remove the cause of overheating.
Keep the air inlets and outlets free of dust to ensure that
maximum heat output is available. Before the start of the
heating season, vacuum-clean the heater to remove any dirt
or dust.
6. Possible Faults
If the heater does not give out any warmth, check that it is
switched on and that the thermostat is set to the
correct temperature. Then check the fuse or miniature circuit
breaker.
If the cause of the fault cannot be identified, contact the
nearest after-sales service center.
You must state the unit E-number and FD-number, as indi-
cated on the type plate (wiring compartment cover).
Any examination of the heater or repair work may only be
carried out by a qualified electrician or after-sales service
technician.
7. Cleaning
Before cleaning, ensure that the heater is disconnected from
the power supply and that it has cooled down. The outer
surface can be wiped with a soft damp cloth. Do not use
scouring powder or furniture polish, as these can damage
the surface.
Dust that collects within the unit can be removed from the
outside using a vacuum cleaner.
8. Technical Data
Power supply voltage
Protection class I
Protection system
Type Output
DXW 307 750 W
DXW 310 1000 W
DXW 315 1500 W
DXW 320 2000 W
DXW 325 2500 W
DXW 330 3000 W
Drilling dimensions (front view)
110
9. Warranty
Authorized dealers can provide information on the terms
and conditions of warranty. The warranty is not valid without
a sales receipt marked with the date of purchase.
Disposal Notice
The product should not be disposed of with
your other household waste
4
1/N/PE~ 230V, 50Hz
Protective earth terminal
IP 20
Weight Width Height Depth Dim. A
(all dimensions in mm)
3.5 kg 577 357 124
3.5 kg 577 357 124
3.5 kg 577 357 124
3.5 kg 577 357 124
4.1 kg 697 357 124
4.1 kg 697 357 124
110
A
357
357
357
357
477
477
91
184
82
52
