FUSE MONITOR

Status LED

There is 3 word with different color light at the bottom side.
It can help user get test result quickly.
Number Word/Color
1 Inactive/Green
2 Active/Yellow There is a current flowing through the fuse.
3 Open / Red The fuse may have blown.

Charging the Battery

Plug the Type-C USB cable to charge the battery.
If the fuse or the vehicle's circuitry is connected to mains
or other power source, LCD may show wrong value while
charging.
Condition
The measured current is less than 0.05A.
That means there is no current on the fuse.
WARNING
3
EN
