TECHNICAL PASSPORT
Oven
Telescopic runners with folding
clip
WARNING
The runners must be placed at
height 2, starting from below. Figure 12.
1. Remove the protective film.
2. Hook the large clips on the upper
rail and extend the runner until it hooks
on the small clips on the lower rail.
Figure 12.
3. You will hear a «click» when the
runner is correctly secured. Figure 13.
4. The notch to fix the tray/support
must remain at the front part of the
oven. Figure 13.
Telescopic runners with direct
clip
WARNING
The single extraction runners must
be placed at heights 1, 2, 3 and 5
starting from below. Figure 14.
The double extraction runners must
be placed at heights 1, 2 and 3 starting
from below. Figure 15.
In 45 cm ovens, the telescopic
runners are positioned at height 1.
Figure 16.
1. Hook the clip on the top rail at the
desired level. Figure 17.
2. You will hear a «click» when the
runner is correctly secured. Figure 18.
3. The notch to fix the tray/rack
support must emain at the front part of
the oven. Figure 18.
