ENGLISH
INSTALL ATION
This information is exclusively for the installer who is responsible for assembly
and electrical connection. The manufacturer will not accept liability for possible
damage caused if you install the oven yourself.

BEFORE INSTALLATION

 To handle the oven, use the grips
at the sides. Do not use the door handle
to lift the oven.
 When installing the oven under
a counter, follow the instructions for
installing it.
 In general, protruding elements
(furniture reinforcements, pipes, socket
bases, etc.) at the back of the unit must
be avoided.
 When the base of the main
power socket is inside the unit in which
the oven is installed, this must be done
in the shaded area. Figure 2.
 The unit in which the oven
is installed and adjacent units must
withstand temperatures higher than
85 ºC.
 The

installation

must be adhered to strictly. If not, the
oven's ventilation circuit may become
blocked, causing high temperatures
that could damage the kitchen unit and
the appliance itself.
 For this purpose, check the unit
measurements and those of the holes
to be drilled in the units, as shown in
the following figures:

Column installation.

60 cm oven: Figure 7*.
45 cm oven: Figure 8*.
* When installing pyrolytic ovens, DO
NOT drill any holes in the unit inside
the shaded areas.

Undercounter installation.

60 cm oven: Figure 9*.
45 cm oven: Figure 10*.
* When installing pyrolytic ovens, DO
NOT drill any holes in the unit inside
the shaded areas.
instructions

ELECTRICAL CONNECTION

The fitter must ensure that:
 The mains power voltage and
frequency correspond to what is marked
on the identification plate.
 The domestic wiring system can
withstand the maximum power marked
on the identification plate.
 After
supply, check that all electrical parts of
the oven are working correctly.
TECHNICAL PASSPORT
CAUTION
WARNING
connecting
Oven
the power
57
