Alarms and Warnings

High temperature alarm

Will be displayed.

The alarm will sound but can be silenced by pressing any of the buttons, however it will return after the pre-set

designated period. If the unit returns to normal operating temperature the alarm etc. will be cancelled automatically.

If this does not occur after 4 hours call your Foster Authorised Service Company.

Low temperature alarm.

Will be displayed.

The alarm will sound but can be silenced by pressing any of the buttons and the unit will continue to operate,

however it will return after the pre-set designated period. If the unit returns to normal operating temperature the

alarm etc. will be cancelled automatically.

Company.

Air Temperature Probe Failure.

Will be displayed.

The alarm will sound but can be silenced by pressing any button.

There is no further action that can be taken by the user in this instance; therefore call your Foster Authorised Service

Company as soon as possible. During this period the unit will continue to operate but have a reduced performance.

Evaporator Temperature Probe Failure. (Freezer Cabinets Only)

Will be displayed.

The alarm will sound but can be silenced by pressing any button.

There is no further action that can be taken by the user in this instance; therefore call your Foster Authorised Service

Company as soon as possible. During this period the unit will continue to operate satisfactorily, but this failure will

have an effect on the defrost and therefore efficiency if allowed to continue.

cleaning/maintenance

N.B. Before internal cleaning, switch off unit.

Cleaning Instructions

Important Cleaning Instructions

Cared for correctly, the cabinet has the ability to resist corrosion and pitting for many years.

The following weekly cleaning regime is recommended.

a. Exterior and Interior: Wash with mild soapy water, rinse with clean water and dry thoroughly.

b. Door and bottom unit cover: Use a proprietary stainless steel cleaner following the

manufacturers instruction.

WARNING:

High alkaline cleaning agent or those containing bleaches, acids and chlorines are very harmful to

all materials. Corrosion and pitting may result from their accidental or deliberate application.

If any of these liquids should come into contact with the unit during general kitchen cleaning,

wipe down the affected area immediately with clean water and rub dry.

Never use wire wool or scouring powders on surfaces.

After cleaning allow the unit to reach its normal operating temperature before reloading with

product. During usage all spills should be wiped clean immediately but care should be taken not

to touch the interior of freezer units as warm skin can 'freeze' to metal cabinets.

These should be inspected on a regular basis and replaced if damaged. To clean, wipe with a warm damp

Door Gaskets

soapy cloth followed by a clean damp cloth and finally thoroughly dry before closing the door.

Condenser

Important: Disconnect the mains electrical supply to the machine prior to removing the condenser

compartment unit cover.

Remove the two screws located at the base of the condenser compartment unit cover and pull forward

taking care not to damage the interconnecting cables to the controller. Clean the condenser using a soft

brush or vacuum cleaner.

NOTE: if there are any stubborn grease deposits etc left on or through the condenser call your Foster

Authorised Service Company to carry out a full service.

Failure to carry out this action may invalidate the warranty of the condensing unit.

If this does not occur after 4 hours call your Foster Authorised Service

When loaded, ensure

Airflow

that air can circulate

around / through

stored products.

Cover all foods and

Food

separate raw and cooked

foods.

operational failure

Checks must be carried out by a competent person.
