Ozone production:
Ion balance:
Operating temperature:
Operating conditions:

5. Installation

5.1. Checks
− Check that the Top Gun is undamaged and that you have received the correct version.
− Check that the data on the packing slip corresponds with the data shown on the product
received.
If you have any problems and/or in the case of ambiguity:
Please contact SIMCO or your regional agent.
5.2. Mounting
5.2.1 Power unit mounting
Mount the power unit in the position you like against a wall or on/under a work table.
5.2.2 Gun holder mounting
Mount the gun holder in the position you like against a wall, on or at the side of the worktop or
on the power unit. Use the holes at the top of the cover for mounting the holder on the power
unit.

5.3 Compressed air connection

Warning:
The compressed air must be clean, dry and free of oil.
The maximum permissible compressed air pressure is 7 bar (100 PSI).
Use an external filter and pressure regulator for this purpose.
The compressed air is connected to the power unit via an 1/8" NPT female nipple. An adapter
nipple (1/8 x ¼ BSP) is included in the supply. Connect the compressed air via a flexible or
rigid line. The line diameter depends on the air consumption. The minimum inside line diameter
must be 4 mm.
5.4 Mains voltage connection
Warning:
Make sure that the equipment is properly earthed.
The wall socket to be used must be easily accessible.
1. Check that the mains voltage corresponds with the value shown on the rating plate.
2. Plug the connection lead into the connector of the power unit.
3. Insert the plug into an earthed wall socket.
Top Gun 97.52.05.04.20
< 0.001 ppm measured at 45 cm from the nozzle
at a pressure of 1 bar
0 +/- 15 volts
0 - 40°C
Light industrial
