USER'S MANUAL FOR TOP GUN III

1. Introduction

Read this manual completely before you install and put this product into use.
Follow the instructions set out in this manual to ensure proper operation of the product and to
be able to invoke guarantee.
The guarantee terms are stated in the General Conditions for the Sale and Delivery of Products
and/or Performance of Activities by SIMCO (Nederland) B.V.

2. Safety

− Electrical installation and repairs shall be performed by a skilled electrical engineer.
− When carrying out work on the equipment: De-energise the equipment.
− If changes, adjusents, etc. have been made without prior consent in writing, or if no original
parts have been used for repairs, CE approval for the equipment will be withdrawn and the
equipment will no longer be under guarantee.
− Make sure that the equipment is properly earthed.
Earthing is needed to ensure proper operation and to avoid electrical shocks upon contact.

3. Use and operation

The Top Gun ionizing air gun allows you to simultaneously clean and neutralize
electrostatically charged parts and to prevent the blown-away particles from being re-attracted.
The Top Gun produces an air flow which is rich in positive and negative ions. When this air
flow is pointed to an electrostatically charged area, electrons are exchanged so that the area is
neutralized and cleaned.

4. Technical specifications

Mains voltage:
Current:
Frequency:
Connector:
Pressure medium:
Max. pressure
Air connection:
Air consumption:
Filter:
Noise level:
Top Gun 97.52.05.04.20
230 V AC
5 mA (standby), 50 mA (in operation)
50/60 Hz
IEC 320
Air (or nitrogen)
7 bar (100 PSI)
1/8 NPT female
68 l/min at 2 bar
130 l/min at 4 bar
210 l/min at 7 bar
0.01 micron
76 dB at 2 bar
89 dB at 4 bar
97 dB at 7 bar
noise level measured at 60 cm distance from the
nozzle
