ReaR PaneL

the rear panel provides the following connectors:
PS/2 mouse
PS/2 keyboard
note: to reach the 8-channel sound effect, the 7th and 8th channels must be out-
put from front panel if you purchase the mainboard with  audio jacks

HaRdWaRe SetuP

this chapter tells you how to install the CPu, memory modules, and expansion
cards, as well as how to setup the jumpers on the mainboard. it also provides the
instructions on connecting the peripheral devices, such as the mouse, keyboard,
etc. While doing the installation, be careful in holding the components and follow
the installation procedures.
CPu & Cooler installation Procedures for LGa775
When you are installing the CPu, make sure to install the cooler to prevent over-
heating. if you do not have the CPu cooler, consult your dealer before turning on
the computer.
the pin-pad side of LGa 775 CPu.
yellow triangle is the Pin
indicator
2
Parallel port
Serial port
VGa port
(optional)
alignment key
Line-in
Lan
Line-out
uSB ports
the surface of LGa 775 CPu.
Remember to apply some thermal
paste on it for better heat dispersion.
alignment key
yellow triangle is the Pin
indicator
RS-out
CS-out
MiC SS-out
(optional)
