rEAr pANEL

the rear panel provides the following connectors:
pS/2 mouse/ keyboard
uSB 2.0 ports
iMportANt
the HdMi, VGA & dVi-d ports only work with integrated Graphics processor.

HArdWArE SEtup

Cpu & Cooler installation for LGA55
When installing a Cpu, always remember to install a Cpu cooler. A Cpu cooler is
necessary to prevent overheating and maintain system stability. follow the steps
below to ensure correct Cpu and Cpu cooler installation. Wrong installation can
damage both the Cpu and the mainboard.
introduction to the LGA 55 Cpu
the surface of the LGA 55 Cpu has two alignment keys and a yellow triangle to
assist in correctly lining up the Cpu for mainboard placement. the yellow triangle
is the pin  indicator.
Alignment key
4
VGA port
HdMi port dVi-d port
yellow triangle is the pin  indicator
LAN
uSB 2.0 ports
Alignment key
Line-in
Line-out
MiC
